Laser Beam Dump Design

Starting at 141 20 trap it beam dumps.

Laser beam dump design.

It can be used for beams of up to 50 w in the wavelength range from 0 1 to 30 µm. Water cooling is provided to remove the absorbed heat. Two standard models are made and these are designed to fit to 25 and 38 series beam delivery. When some kind of pump laser sends a beam to another device e g a titanium sapphire laser or an opo on which one needs to temporarily work without the pump light e g.

Kentek s beam dumps available in water cooled and air cooled configurations employ a kentek original design that creates an infinite internal trap of laser beam energy. Cleaning some mirrors one may insert a beam dump between the devices instead of turning off the pump laser. Air cooled beam dump 990 0800 is designed to block a cw or a pulsed laser beam. Beam dumps introduction bdu series beam dumps are designed to absorb incident co2 laser radiation in a hollow conical section of the dump block.

This is must have in every lab device increases safety and reduces risk of laser damage by trapping the beam entered into the aperture. The pl15 laser beam dump has a reflective factor of less than 10 4 fifty times more efficient than classical laser beam traps. Trap it laser beam dumps are available with varying aperture diameters up to 4 to accommodate the largest diameter beams in the industry. Trap it laser beam dumps utilize a dual cone design to eliminate harmful radiation reflected out of the beam dump.

Our laser beam dumps fits for most beam sizes and can be simply used everywhere. It can withstand power densities to 7kw cm at full power and has a spectral range from 0 19 to 20µm. To clean the active surface disassemble the unit and gently wipe the. The bdfl500a bb 50 is a fan cooled beam dump with a 50mm aperture for up to 500w.
